    GCE 1200V Master Slave BMS 160A 200A 250A high voltage BMS(HV BMS) With 16S 32S 48S 52S BMU For ESS

    Ask Lasest Price
    Brand Name : GCE
    Model Number : RBMS-S20-160A-1500
    Certification : CE
    Price : negiociate with ellen@hngce.com
    Payment Terms : L/C, T/T
    Supply Ability : 1000sets/Month
    Delivery Time : 15-20 days
    • Product Details
    • Company Profile

    GCE 1200V Master Slave BMS 160A 200A 250A high voltage BMS(HV BMS) With 16S 32S 48S 52S BMU For ESS

    GCE 1200V Master Slave BMS ​160A 200A 250A high voltage BMS(HV BMS) With 16S 32S 48S 52S BMU For ESS

    1200V Master Slave BMS Topology Diagram:


    The RBMS (Rack Battery Management System) is a master-slave battery management system (master-slave BMS) developed for large-scale high-voltage battery energy storage system applications. It adopts a distributed architecture and modular design concept, with a high degree of configurability, making it easy to assemble, debug, and maintain. It is suitable for various battery energy storage systems with a high voltage DC (high voltage BMS(HV BMS)) of more than 1000V.


    This product can be configured with a minimum of a two-tier architecture (BMU + RBMS), suitable for applications ranging from 50 kWh to 200 kWh. When combined with industrial computers and battery pack management software, it can form a three-tier architecture (BMU + RBMS + SBMS), suitable for applications from 50 kWh to 2 MWh. When combined with servers and power plant battery management system software, it can form a four-tier architecture (BMU + RBMS + SBMS + BBMS), suitable for applications from 2 MWh to 1000 MWh, in order to meet the needs of different projects.


    The following is a system topology diagram for a multi-rack three-tier architecture (BMU + RBMS + SBMS) system:


    1200V BMS Compatible Inverters:


    1200V BMS Specifications:

    SPECIFICATION
    Basic Parameters
    Max current
    200A
    300Rated voltage
    300-1500V
    Power consumption
    ≤15W
    Current sampling accuracy
    1%FSR
    Insulation withstand voltage
    4000VDC <1mA 1min
    Protection level
    IP20
    Dimension(W*H*D)
    482 * 180 * 500(mm)
    Net weight
    ~22Kg
    Communication Port
    Communication port with BMU
    CAN
    Communication port with UPS
    RS485/CAN
    Communication port with SBMS
    RS485/CAN
    Communicate with PC software
    Ethernet
    Basic Functions
    Battery charge and discharge management
    Support
    Battery temperature management
    Support
    IAP upgrade
    Support
    System protection parameter setting
    Support
    Short circuit Protection
    Support(1500V 20KA 20ms)
    Precharge function
    Support
    Parallel loop current control
    Support
    Event record
    Support 5000 records
    Middle line system
    Support(Optional)
    Dual power supply
    Support
    Optional Functions
    Monitor Insulation
    Optional
    HMI display
    4.3", 7" display(optional)(external)
    Standalone or Parallel
    Set-up completed before leaving the factory
    Dry contact
    2 dry contact outputs (optional)
    Others
    Color
    RAL7035 Grey
    Operating ambient temperature
    -20℃~60℃
    Operating ambient humidity
    5%~75%RH
    Compliance with national standards
    GB/T 16935.1 GB/T 17626.2 GB/T 17626.5
    Certification
    CE

    Master Slave BMS Applications:

    High Voltage Battery Management Systems (BMS) are widely used in energy storage systems, such as residential and commercial storage, as well as grid storage, optimizing the management and utilization of solar and wind energy. Additionally, in industrial applications, BMS manage the batteries of Automated Guided Vehicles (AGVs) and Uninterruptible Power Supplies (UPS), ensuring the reliability and continuous operation of these systems. Through monitoring, balancing, protection, and communication functions, high voltage BMS(HV BMS) optimize the performance, safety, and lifespan of various non-automotive battery-powered systems.

    1200V BMS --- Master Slave BMS Manufacturer in China:


    Hunan GCE Technology Co., Ltd.(GCE) is a high-tech company specializing in the R&D and production of BMS energy storage systems and batteries for over 10 years. Our products are mainly used for industrial and commercial energy storage and home energy storage.
    BMS 30-75S uses an integrated design and relay solution to meet the lithium battery demand of multiple strings of small capacity batteries. Significantly reduce user usage costs.
    The 60s-405S adopts a three-tier architecture that can meet the series and parallel requirements of single high-capacity lithium batteries within 1500V.
    7.68KWh-40.96KWh Stackable Home Energy Storage System supports 3-8 HV battery modules connected in Sereis, with Small volume, light weight, plug-in built-in modules, built-in Smart BMS, easy to install and maintain.

    Solar Energy System BMS Battery Management System 384V 409.6V 480V 512V 563.2V HV BMS 125A For Photovoltaic System 6

    Q & A:


    Q: Are you a manufacturer or a trading company?
    A: We are a manufacturer with over 10 years of R&D experience in production. and we sincerely welcome you to visit our factory.

    Q: Can I get some samples?
    A: Yes, a sample order is available for quality checking and market testing.

    Q: What kind of cells are applicable to this Battery Management System?
    A: LFP, NMC, LTO etc.

    Q: How about the delivery time?
    A: The lead-time usually takes about 15 to 20 working days accordingly to the specification of your order and quantity.

    Q: What are your terms of payment?
    A: Advanced T/T is the main payment term, and other payment terms are negotiable. Please contact us for the details.

    Q: What are your warranty terms?
    A: 3 years for RBMS and 1 year for BMU/PCBs

    Q: Can you produce BMS with customization requirements?
    A: Yes, OEM & ODM service is acceptable.

    Q: How does your factory do regarding quality control?
    A: Quality always comes first. All our products go through strict quality control processes from incoming material to the
    assembling process. Each product will be tested before packing & shipping.

    Q: What is the voltage range supported by GCE high voltage BMS(HV BMS)?
    A: GCE high voltage BMS(HV BMS) supports a voltage range from 96V to 864V.

    Q: What is the current capacity range available for GCE high voltage BMS(HV BMS)?
    A: GCE high voltage BMS(HV BMS) offers current options of 50A, 125A, 160A, 250A, 400A, and 500A to accommodate various system requirements.

    Q: Which inverters are compatible with GCE BMS?
    A: GCE BMS supports CAN & RS485 protocols and it is compatible with the protocol of most well-known inverter brands in the market, such as DEYE, Growatt, Goodwe, Sofar, Sungrow, Kehua, ATESS, Megarevo, Sinexcel, Pylontech, Solis Sermatec......


    .
