OEM 192V 125A Relay high voltage BMS(HV BMS) with 15S BMU for BESS UPS

Sistemas De Energia Solar Solar Energy System Lifepo4 Battery For LFP

NCM LTO BESS UPS Solar energy system UPS power For Lifepo4
lithium-ion batteries For UPS ESS Solar BESS For High Voltage battery

energy storage systems Lifepo4 battery BMS For Large scale ESS Container

BESS Micro Grid ESS Home ESS Carport ESS Overall Solution BMS Battery Management System

Solution Of BMS: One complete set of HV 60S192V 125A BMS solutions includes: 1set Master BMS, Model#: RBMS07-S23-125A192V 4sets of 15S Slave BMU Model#: BMU07-15S8T48F 4sets of 15S Wire Harness, including voltage&temperature acquisition wires, BMU communication wires, Fan power wires.

Product Features: Perfect self-test and operational status detection, with HMI display, and system operation information at a glance. Advanced Battery Management System -- The highly integrated battery management system enables seamless monitoring. Automatic circulation control and automatic parallel machine offline control can be easily parallel batteries. (Model suffix selection D). Flexible communication interface protocol --- The company comes with the company's communication protocol, but also according to customer needs to adapt to PCS of different manufacturers. Capacity is large --- Built-in large-capacity memory chips can store a large number of key operational data, but also can install an SD card for offline access. AC, DC Dual power supply design. 3U compact in size, master BMS and Slave BMU make its assembly flexible. 3.5" built-in touchscreen enables BMS operation easily. LAN, RS485, and CAN communication channels, together with GCE's unique software, our BMS can exchange data with PC and other devices.

12S-24S BMU(Slave) 12S-24S BMU has 8pcs of temperature sensors, Fan voltage 48V(17S-24S 12V), voltage detection range 0-5V,12V power supply,consumption less 20mA, CAN2.0 B communication	Wire harness- Signal acquisition wire 18 Pin+20Pin wire, standard length is 600mm,900mm,1200mm tempreture sensor wire: standard length is 600mm,900mm,1200mm Fan wire: 600mm	Wire harness- communication wire Communication wire is connecting from master BMS to each BMU with cascade connection, the last port is for terminal resistance

Specification:

Applications:

Documents Download:

Linkage for downloading specifications for master BMS and slave BMU:

GCE_RBMS specification--EN--V1.0.pdf

GCE 12-16S BMU-specification-UL-V1.0.pdf

Linkage for downloading of BMS demand information collection form:

high voltage BMS(HV BMS) info collection form EN2021-04.do...

For more information about the products, please contact me.

About US:

Hunan Group Control Energy Technology Co., Ltd.(GCE) is a high-tech company specializing in the research and development of BMS and lithium battery peripheral equipment.

The high-performance intelligent lithium battery management system produced by our company adopts the international leading technology,

Which greatly improves the battery management efficiency and prolongs the service life of lithium battery.

The advanced BMS control strategy avoids the difficulties and instability faced by most competitors for our BMS.

Contact Information:

Bruce Liu
Marketing Director
bruceliu@hngce.com

0086-0136-2009-7954

Hunan group control energy technology Co., Ltd. (GCE) is a high-tech company specializing in the research and development of BMS and lithium battery peripheral equipment.

working in the factory:

 The high-performance intelligent lithium battery management system produced by our company adopts the international leading technology, which greatly improves the battery management efficiency and prolongs the service life of lithium battery. The advanced BMS control strategy avoids the difficulties and instability faced by most competitors for our BMS.

4S to 24s low voltage software BMS has a wide range of uses, rich product interfaces, strong scalability and secondary development compatibility; 30s to 75s BMS adopts master-slave integrated design and relay solution to meet the lithium battery demand of multiple strings of small capacity batteries. Greatly reduce the use cost of users; 60s-270s adopts master-slave three-level architecture, which can meet the series and parallel requirements of high-capacity single lithium batteries within 1000V.

By mastering the core technology of BMS and inventing on this basis, our company has developed a variety of lithium battery peripherals to meet the high-quality needs of the market.
