Product Description:

The Battery Management System is designed to provide optimal performance and functionality for lithium-ion batteries. It can be used in a variety of applications, such as UPS, Solar Energy Storage System, and Battery Energy Storage System. This system provides reliable communication interface with CAN/RS485 and communication port with SBMS with RS485/CAN. It also has an operating temperature range from -20℃ to 60℃ with IP20 protection level. This system helps to reduce the risk of overcharging or discharging and ensures long-term battery life and safety.

Features:

• Product Name: Embedded Integrated BMS
• Maximum Overload Capacity: IP20
• Battery Type: Lithium-ion(LFP)/NMC/LTO
• Communication port with UPS: RS485/CAN
• Short Circuit Protection: 7.5KA 20ms
• Battery Management System Lithium Ion: Yes
• Display Method: 6-digit LED indicator (including 1 for fault indication, 1 for running indication, and 4 for SOC power indication)

Technical Parameters:

Applications:

GCE's RBMS07-S-75S100A Battery Management System (BMS) offers reliable and secure power source solutions for customers who need a backup battery system. This BMS is specifically designed for LiFePO4 battery packs, providing superior protection from overcharging and discharging. It has a CE/RoHS/SGS/MSDS certification and a minimum order quantity of 1 set. The price is negotiable and can be discussed with emma@gcebms.com. The packaging details include corrugated carton, bundles, pallets, and wooden boxes. The delivery time is 15-25 days and payment terms are FOB/CFR/EXW. The supply ability is 8000 sets/month. The power consumption of this BMS is ≤10W. The communication port with SBMS is RS485/CAN. The operating temperature is -20℃~60℃.

This BMS provides protection against overcharge, over-discharge, overload, short-circuit, and more. It is also compatible with LiFePO4 battery packs, making it a great choice for customers looking for a reliable bms for lifepo4.

Customization:

• Brand Name: GCE
• Model Number: RBMS07-S-75S100A
• Place of Origin: China,Hunan
• Certification: CE/RoHS/SGS/MSDS
• Minimum Order Quantity: 1set
• Price: negotiable email with emma@gcebms.com
• Packaging Details: Corrugated Carton, bundles, pallets, wooden box
• Delivery Time: 15-25 days
• Payment Terms: FOB/CFR/EXW
• Supply Ability: 8000 sets/month
• Communication port with BMU: CAN
• Communication port with SBMS: RS485/CAN
• Operating ambient humidity: 5%~75%RH
• Event record: Available (5000)
• Specialized for lifepo4 battery: Our BMS is especially designed for lifepo4 battery and offers a reliable solution for battery management.

Packing and Shipping:

When shipping the Battery Management System, it is important to ensure that all components are securely packaged and labeled correctly for easy identification.

• Choose a box that is large enough to fit all components and padding material.
• Place the Battery Management System and accessories in the box, filling any empty space with padding material.
• Securely tape the box shut.
• Label the box with the correct recipient address and a list of the components inside.
